PM-740S ECO Traveling Head Cutting Machine (40tons)
ECO Traveling Head Cutting Machine (40tons)

Equips with MINZ Energy System,consumes no energy when not cutting.Temperature of hydraluic fluid and motor is reduced 30℅,and uses 70℅less electricity comparing to traditional cutting machine.

Option add-on Barcode Scan System to instantly set up each Cutting Die's required cutting distance,Remote Manage System to centralize production date,and Fast Set Up System to configure cutting distance within 5 seconds with precision of 0.5mm.

Model PM-740S
Cutting Force 40tons
Average KW 0.3 ~ 0.5 KW
Cutting Area 600 x 1600mm
Stroke 5 ~ 150mm
N. W. 2250 kgs
G. W. We will supply the information before delivery
Dimension 2230 x 1540 x 2080 mm
Packing Size We will supply the information before delivery
Hydraulic Oil 90L

We reserve the rights to change the specs and dimension above without further notification.
